​Produkte | Ladelösungen für Elektrofahrzeuge

Input rating

Three-phase:260V-530V AC Full (30kW,40kW)

Output rating

200V-1000V DC(Three-phase)

Number of phases/wires

3ph/L1,L2,L3,PE,N

Efficiency

>95%

Power factor

>0.99

Current Total Harmonic Distortion

<5%

Exhibition

7-inch LCD Touch Screen Display

Language

Multi-languages,English(default)

Charging interface

CCS2/GBT/CCS1/CHAdeMO

Ingress protection

IP54

Sheild

Over Current,Under Voltage,Residual Current,Surge Protection,Short Circuit,Over Temperature,Ground Fault

Operating temperature

-40℃to+75℃(derating when over 55℃)

Storage temperature

-40℃to+85℃

Humidity

<95%Relative Humidity,Non-condensing

Height

Up to 2000 m(6000 feet)

Cooling

Air-Cooling

User authentication

NFC Card /Online Payment System

Network interfaces

Ethernet(standard);Wi-Fi,4G(optional)

OCPP protocol

OCPP1.6/OCPP2.0

Charging cable length

5m

Dimensions(L*W*H)

270mm*560mm*780mm

Weight

30kW-58kg;40kW-64kg
